CNC Mill
cnc mill - Featuring: NHX 4000
The NHX 4000 is a horizontal machining center enabling high-efficiency, continuous machining and mass production machining. It is equipped with the latest spindle, the speedMASTER, ensuring high-speed and stable high-precision machining with the thick, high-rigidity bed. The X- and Z-axis guideways are positioned to maximize the rigidity of the bed, column and spindle. The entire structure is optimized for increased performance in static and dynamic rigidity. As a result, this model achieves the highest level of speed and accuracy demanded of a horizontal machining center. The distance between the spindle end face and the center of the pallet is short, so machining can be done using short tools even near the center of the pallet. This enables the model to deliver stable performance in various types of machining.
Mori Seiki SV-50 - Vertical Machining Center
Automatic pallet changer 10,000 RPM Spindle 30-tool ATC High speed machining package Automatic tool length preseter Tool breakage detector Travels are 31"-X, 20"-Y, 20"-Z
Mori Seiki NH 4000 DCG - Horizontal Machining Center
Pallet changer 14,000 RPM Spindle 4th axis rotary table 60 tool ATC High pressure coolant Automatic tool length preseter Tool breakage detector Travels are 22.0"-X, 22.0"-Y, 24.8"-Z
Haas VF4 - Vertical Machining Center
12,000 RPM Spindle 24 tool ATC Travels are 50"-X, 20"-Y, 25"-Z
Hass VF6 - Vertical Machining Center
8,100 RPM spindle 24 tool ATC Travels are *64"-X, 32"-Y, 30"-Z
Mori Seiki MV40 - Vertical Machining Center
Automatic pallet changer 8,000 RPM spindle 30 tool ATC Travels are 21"-X, 16"-Y, 20"-Z
Milling
As the art of machining has evolved, the tool of choice has become the CNC (Computerized Numerical Control) Milling Center. Duyck Machine employs the use of several of these in our manufacturing facility. These high precision machine tools are used in both production and prototype machining for close tolerance work. They all sport automatic tool changers and in some cases, pallet changers, to make the most of our production capabilities. General sizes of the working envelope of our machines are 31 inches by 18 inches, however for some applications we can go as large as 64"X 32" X 30".
